l Embedded Linux operating system, safe and stable operation;
l Using low-power high-performance processors, the equipment operates with low power consumption and less heat;
l Embedded with the industrial leading deep learning face recognition algorithm, the face recognition rate is ≥99.97%;
l Accurate and rapid recognition and comparison at millisecond level, face recognition speed (1:N) ≤0.2S/person;
l Professional ISP image processing, fearless glare, backlight and darkness; adapt to complex light environment;
l Support the largest face recognition mode, support face selection, face enhancement and face exposure, and improve image quality;
l Support the recognition remote control of 0.3~1M, effectively preventing the misrecognition of persons who are far away;
l 2 million binocular cameras, supporting live detection function, effectively solving the problem of deceiving photos, videos and other methods;
l Standard configuration of 10,000 face database and 50,000 record storage, meeting the access control and attendance needs of enterprises of all sizes;
l Seamlessly connect to various cloud platforms such as WeChat and Ruishiyun to realize all-round intelligent access control and attendance management;
l Support personnel, equipment, authority group management, and batch registration;
l Support swiping face to open, access situation. Equipment status is clear at a glance, and the data log can be exported with one click;
l Support wired, WIFI, Bluetooth communication methods, simple wiring;
l Optional face recognition wake-up function to avoid unwilling recognition of whitelisted persons;
l 4-inch high-definition screen, with resolution 480*800;
l Natural light and near-infrared fill light, supporting low-light environment use;
l Support online and offline working modes;
l Provide comprehensive secondary development technical support;
l Wall-mounted/desk vertical installation method, exquisite and small appearance, simple and practical function;
Basic data | Product name | Face recognition access control attendance terminal |
Product model | STD-5MR042Y1-W | |
Operating system | Embedded Linux system | |
Display screen | Size | 4-inch screen |
Resolution | 480*800 | |
Camera | Resolution | 200W pixels (1920×1080) |
Camera | HD fixed focus 4mm | |
Wide dynamic | Digital wide dynamic | |
Fill light | Natural light and infrared light, recognition status light | |
Smart functions | Face detection | Maximum face detection |
Storage | 10,000 face base library, 50,000 record storage | |
Recognition mode | Only human face | |
Accurate recognition | 1: N recognition speed ≤0.2S/person, recognition accuracy ≥99.97% | |
Recognition distance | 0.3-1M | |
Live detection | Binocular live detection | |
Alarm management | Information display (subsequent support for identification parameter configuration) | |
Cloud platform | Enterprise WeChat, Ruishiyun | |
Trigger recognition | Support face recognition wake-up function | |
Screen saver | Not currently supported | |
Operating mode | Support online and offline work | |
Rich interface | Communication method | Support wired, WIFI, Bluetooth |
Network interface | 1 10/100M network adaptive, RJ45 interface | |
Doorlock interface | Door opening signal, door sensor status, switch button | |
RS485 interface | RS485+、RS485-、GND | |
Reset interface | Not supported currently | |
Tamper switch | Not supported currently | |
Audio interface | Built-in speaker, voice broadcast | |
Platform agreement | SDK, WebSocket, HTTP reverse | |
General parameters
| Equipment power | DC 12V/1.5A |
Working environment | Indoor environment and temperature: -20℃～55℃ Humidity: 10～90%RH | |
Protection level | Anti-static: contact ±6KV, air ±8KV | |
Installation method | Wall-mounted type, table vertical type, support 86 boxes | |
Equipment size | Length: 116mm, Width: 100mm | |
Weight | About 0.3kg |
Product size (unit mm):
